1PH8087-1UM02-0LA1

SIEMENSSPINDLE SERVO MOTOR
ÜRÜN STOKTA BULUNAMADI.
SIMOTICS M compact asynchronous motor 3000 rpm 4.8 kW 15.3 Nm 17.3 A 284 V 3300 rpm 5.2 kW 15 Nm 17.1 A 303 V 3600 rpm 5.7 kW 15.1 Nm 17.1 A 329 V 3900 rpm 6 kW 14.7 Nm 17.1 A 357 V forced ventilation; direction of air flow DE--> NDE; IP55 degree of protection Incremental encoder 20-bit Without commutation position (encoder IN20DQ) with DRIVE-CLiQ interface DESIGN IM B5 (IMV 1,IM V3) PLAIN SHAFT WITHOUT FITTED KEY; BEARING: PERFORMANCE, VIBRATION SEVERITY GRADE SPECIAL/B; SHAFT A. FLANGE ACCURACY GR. SPECIAL TERMINAL BOX (ABOVE) CABLE ENTRY ON THE RIGHT SIGNAL CONNECTION D-END
